iZEN Chassis Design

Supports 36-bay sas3,sata3 3.5" ,2.5"HDD cage 12Gb/s Mini-SAS HD backplane

Support SAS 3.0 12Gb/s, SATA 3.0 6Gb/s interface or backward compatibility.
Support 5 pcs SFF-8643 internal MH1 mini-SAS HD interface connector for HBA card.
Built-in front access USB3.0 port
Optional internal 2-bay 2.5 HDD cage for OS drive ( SAS/SATA ) or Cache (NVMe) buffer use
SATISFICATION- Whenever you have any queries of products, we’ll dive right in and find out the root cause and feedback the best solution.

SPECIFICATIONS	4U SERVER RACKMOUNT CHASSIS	ACCESSORY
M/B	eATX 12":X13"	1	2.5" DRIVE BAY*2
Drive Bays	36X3.5" hot-swap	2	PSU 800W, CRPS 2U 1600W
Front Control	POWER ON/OFF,UID,USB3.0	3	I2C, 4-pin, 600mm
Indicators	POWER STATUS, HDD STATUS, FAN STATUS,LAN ACTIVITY	4
Cooling Fans	80X38 3PCS	5
HDD Backplane	SAS3.0,SATA3.0 X8 12Gb/s Mini-SAS (SFF8643)	6
Expansion Slots	7X Full Height
PSU Form Factor	PS2, PS2 REDUNDANT 80Plus Meet CE Rohs	DOWNLOAD
Material	AL6061,1.0mmSGCC,ABS-PC	1	Datasheet	S436C Datasheet
Net Weight	21.5kg
Gross Weight	25.2kg
Dimensions (DxWxH)	650X431X176 (mm)
