A524A
A524A
Supports AI 5 PCI-E 5 GPUs
.
 |
 |
 |
 |
 |
| SPECIFICATIONS | AI 5 PCI-E 5 GPUs | ACCESSORY |
||||
|---|---|---|---|---|---|---|
| M/B | SSI EEB (12”x13.2“)" | 1 | ||||
| DRAM | 8 DDR5 SODIMM | 2 | ||||
| Front Control | POWER ON/OFF,RESET SW,USB3.0 | 3 | ||||
| Indicators | POWER STATUS, HDD STATUS | 4 | ||||
| Cooling Fans | 80X38 4PCS, 120X25 3PCS | 5 | ||||
| USB | 6 x USB 3.2 Gen2 | 6 | ||||
| Expansion Slots | 7 PCIe SOLT (side), | |||||
| PSU Form Factor | 5x 1600W~3000W CRPS | DOWNLOAD |
||||
| Material | 1.0,1.2 mm SGCC | 1 | Datasheet | A524A Datasheet |  |
|
| Net Weight | 24kg | |||||
| Gross Weight | 28kg | |||||
| Dimensions (DxWxH) | 760X438X222 (mm) | |||||
