iZEN Chassis Design

Supports 8.4" LCD Keyboard with a built-in touchpad 2x2.5 HD

8.4” LCD screen, resolution 1024*600
With drawer keyboard and mouse
Built-in front access USB3.0 port
3 COM at the back
SATISFICATION- Whenever you have any queries of products, we’ll dive right in and find out the root cause and feedback the best solution.

SPECIFICATIONS	4U RACKMOUNT CHASSIS with 8.4" Screen LCD	ACCESSORY
M/B	EEB-ATX 12:X10.5"	1	2.5" DRIVE BAY*2
Drive Bays	2X2.5" SDD	2	PSU Redundant 1200W,FLEX		500W
Front Control	POWER ON/OFF,,USB3.0	3
Indicators	POWER STATUS, HDD STATUS, FAN STATUS,LAN ACTIVITY	4
Cooling Fans	812X25 2PCS	5
HDD Backplane		6
Expansion Slots	7X Full PCI-E
PSU Form Factor	4U CRPS 1200W Platinum, 1U FLEX 500W Platinum Meet CE Rohs	DOWNLOAD
Material	AL6061,1.0mm SGCC,	1	Datasheet	451 Datasheet
Net Weight	9.3kg
Gross Weight	13.0kg
Dimensions (WxHxD)	428X177X510 (mm)
